[E² Skin] SlyK Onyx

WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
SlyK Onyx Skin







v1.013
Added in yellow button for client mode on tuner config (openvix)


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Changeset V1.015
Minor update - Changed the font reference for infobar single epg. Also added in colours for LCD.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk onyx 1080 - v1.04

- fixed the progress bar on movie planner. It was the wrong size.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 v2.13

Added in option for xpicons in infobar
Fixed ratings star position on IMDB
Removed some icons on infobar and epg that was causing an error on on Pure2 images.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 v2.18

Fixed the incorrect folder in the IPK that was causing a crash
New WLAN screens
New EPG importer filter screens
New Softcams screens
New Virtual Keyboard (and graphics for legacy virtual keyboard)
New Flash Online screen
New Multi Boot Screen
New main EPG layout (better for IPTV)
New Channel Select screen (better for IPTV)
Now improved Top Picks Mod​


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.19) **last updated 22/07/2019

-Skinned open multiboot plugin









Recommended Settings

Channel selection settings...

Show event-progress in channel selection: Progress bar right
Show channel numbers in channel selection: yes
Show crypto Icons: Left from service/name
Show picons in service list: your choice?
Number of rows 14

Multi EPG settings....

Number of rows: 14 (this settings seems to have stopped working on OpenAtv)

Single EPG Settings...

Number of rows: 14

Graphical infobar EPG Settings…

Number of rows: (set in skin)
All font sizes: 0
Timeline font: 0
Service width: 490 minus picon width if picons shown
Info icon width: 75
Time scale 120 minutes

GraphicalEPG settings…

View mode: graphics
Service Title mode: Service number and Service Name
base time: 15 minutes
service with: 490 minus picon width if picons shown (important)
picon width: 100
info icon width: 75
time scale: 120 minutes

EPG Settings...

Show EIT now/next in infobar....YES
Enable EIT EPG.... YES

Movie Planner settings… (file list button… menu…settings)

Number of rows 8 - 14
use extended list - slyk onyx planner - (see movie planner mod in my dropbox skin folder)
show status icons in movielist - icons
show icon for new/unseen - yes

OSD settings… (Usage & GUI… OSD settings) – vix menu locations will be slightly different

2nd Infobar – 2nd infobar INFO
Show infobar picons – yes
Show infobar on skip forward/backward - yes (required for movies pause icon)
Show channel number in infobar – yes
Show picon background colour – Disabled
Show crypto info in infobar – Two lines
Show PVR status in MoviePlayer infobar – yes


How to enable toppicks

Install the toppicks ipk file

make sure these 2 script files have executable rights.

/usr/script
(/usr/scripts for openvix)

skypicker.sh
skyscraper.sh
Right click the file in your ftp software and edit file permissions to 755 or execute checked for owner/group/public.


Navigate to

/etc/cron/crontabs
edit "roots" file

for example below is my 9am scraper as set in the above screen shot.
the image picker is set to run every 30 mins.


Code:
0 9 * * * /usr/script/skyscraper.sh
*/30 * * * * /usr/script/skypicker.sh

If you don't want to use the toppicks and want to remove the graphics edit skin.xml on your box.
/usr/share/enigma2/slyk-onyx/skin.xml

comment out the toppicks import screen.

Code:
<!-- <include filename="/usr/share/enigma2/slyk-onyx-1080/o-toppicks.xml" /> -->


Movie Planner Mod

Install the relevant movieplanner ipk for either openatv or openvix
Reboot your GUI

Press menu on the movie planner screen and go into settings.
Number of rows - <= 14

Use extended List - Slyk Onyx Planner.


Thanks @ KiddaC


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.20) **last updated 23/08/2019

-A few bug fixes.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.21) **last updated 26/08/2019

-Amended open multiboot screen to work on OpenVIX


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.22) **last updated 05/09/2019

A few slight tweaks.
New global toppicks ipk for use with all my newest skins.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.23) **last updated 07/09/2019

-Added in all the various image's multiboot screens


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.24) **last updated 13/09/2019

-General code clean up.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 (Version 2.27) **last updated 15/07/2020

-Should now work on OpenVix again.
-Top Picks V6.0 *new*

Install first for all my skins - only needs installing once
enigma2-plugin-skins-kiddac-shared-components_1.02_all.ipk


kalkan99

VIP
Messages
2,410
Slyk Onyx 1080 (Version 2.35) **last updated 17/05/2023


Attachments

  • enigma2-plugin-skins-slyk-onyx-1080_2.35.20230517_all.ipk
    3.3 MB · Views: 17

WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 v2.38

Nothing new. Just code clean up, for those people who always want the latest.
Github updated.

Last edited:

WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 v2.39

Smaller button font to fit larger text
Added new openatv software update screen
Added a few scrollbars to some lists
Fixed information screens and added PictureInformation screen (information > receiver > info button)
Playing around with message box resize code

Github updated.


WaRp

(∩`-´)⊃━☆゚.*・。゚
Staff member
Administrator
Messages
32,269
Slyk Onyx 1080 v2.40

Fixed openatv multiboot screen list alignment


Github updated.


kalkan99

VIP
Messages
2,410
Slyk Onyx 1080 v2.43
18.08.2024

fixed more stupidity from openatv.
Skinned the skin selector screen. Another pointless change.


Attachments

  • enigma2-plugin-skins-slyk-onyx-1080_2.43.20240818_all.ipk
    3.2 MB · Views: 23
